Nova 3D GEM3 Dental Resin 3D Printer

The Nova3D Gem 3 Dental Resin 3D Printer is a high-resolution professional 3D printer designed for dental laboratories, clinics, and professionals who need detailed and accurate resin prints. With a 9072 × 5120 resolution, 17 × 17 μm pixel size, and a 154 × 87 × 120 mm build volume, the Gem 3 is well suited for producing precise dental models and other detailed applications.

Its advanced optical system combines a 7th-generation COB light source with a light homogenizer, helping provide consistent UV exposure across the printing area. The integrated air-cooling system supports stable performance during longer printing sessions.

Key Features of Nova3D Gem 3 Dental

High-Resolution Dental Resin Printing

The Gem 3 features a 9072 × 5120 resolution LCD with a 17 × 17 μm pixel size. This enables the printer to reproduce fine details, sharp edges, and intricate features required for accurate dental models.

Its high-resolution printing capability makes it suitable for dental professionals who prioritize detail, dimensional accuracy, and smooth surface quality.

Designed for Dental Applications

The Nova3D Gem 3 Dental is built for professional resin printing workflows where accuracy and consistency are important. Its high-resolution LCD, controlled UV exposure, and industrial motion system make it suitable for a variety of dental applications.

It can be used for dental models, orthodontic models, diagnostic models, and other detailed dental resin prints, depending on the selected material and workflow.

Advanced COB UV Light Source

The printer uses a 7th-generation COB UV light source with a light homogenizer to provide consistent illumination across the printing area.

With an optical power intensity of 5000 μW/cm² and a 405nm UV wavelength, the Gem 3 provides controlled exposure for resin printing.

Consistent UV exposure helps maintain reliable curing and detail reproduction throughout the build area.

Industrial Ball Screw Motion System

The Gem 3 Dental uses an industrial ball screw and industrial stepper motor for its motion system. This provides controlled Z-axis movement during the printing process.

Stable and precise movement is especially important when producing detailed dental models where dimensional consistency matters.

Flexible Layer Thickness

The Nova3D Gem 3 Dental resin 3D printer supports layer thicknesses from 20 μm to 200 μm, with 20 μm increments.

Finer layer settings can be used when greater surface detail is required, while thicker layers can help improve printing efficiency for suitable applications.

Printing Speed Up to 70 mm/h

The Gem 3 offers a rated printing speed of up to 70 mm/h. This allows dental professionals and laboratories to produce detailed resin models efficiently.

Actual printing speed depends on factors such as resin type, layer thickness, exposure settings, model geometry, and slicing parameters.

Compact Size for Dental Workspaces

With dimensions of 335 × 315 × 436.3 mm, the Nova3D Gem 3 Dental maintains a relatively compact footprint while providing a 154 × 87 × 120 mm build volume.

Its size makes it suitable for dental laboratories, clinics, workshops, and professional environments where workspace is limited.

Dental Applications

The Nova3D Gem 3 Dental can be used for a range of dental resin 3D printing applications, depending on compatible materials and validated workflows.

Common applications include:

• Dental model printing
• Orthodontic models
• Diagnostic models
• Detailed dental prototypes
• Educational dental models
• Other precision dental resin applications

Its high-resolution LCD and 405nm UV exposure system make it suitable for applications where fine details and accurate model reproduction are important.

Compatible Slicing Software

The Nova3D Gem 3 Dental supports several popular resin 3D printing slicers, including NovaMaker, Chitubox, Lychee Slicer, and Tango Slicer.

Models can be prepared using common STL and OBJ file formats, giving users flexibility when preparing dental designs for printing.

Why Choose the Nova3D Gem 3 Dental?

For professionals looking for a high-resolution dental resin 3D printer, the Nova3D Gem 3 Dental combines detailed printing, consistent UV exposure, industrial motion components, and flexible layer settings in a compact professional machine.

It is a practical solution for dental laboratories, clinics, and professionals who require accurate and detailed resin 3D printed models as part of their digital workflow.

Nova3D Gem 3 Dental Specifications
